Step 30: Attach Swings
Other Parts
A: Using 1 Threaded Clip per chain, join 1 Long Swing Chain to each side of the swing belt seat. Make sure to
close the Threaded Clip tightly using an adjustable wrench. (g. 30.1 and 30.2).
B: Using 1 Threaded Clip per chain, join the Short Swing Chain to the Acro Bar and Acro Handle. Make sure
to close the Threaded Clip tightly using an adjustable wrench. (g. 30.2 and 30.3)
C: Attach the other end of the swing chains to the Quick Clips attached to the swing hangers. (g. 30.1)
1 x Acro Bar
2 x Acro Handle
2 x Swing Belt Seat
2 x Short Swing Chain
4 x Long Swing Chain
6 x Threaded Clips
Short
Swing
Chain
Quick Clip
Swing Seat
Long Swing Chain
Threaded Clip
Tighten Clip using
adjustable wrench
Threaded Clips
attach to seat and
Acro bar.
Swing Seat
Chain Link
Acro Bar
Acro Handles
Fig. 30.2
Fig. 30.3
Fig. 30.1
