Wood Parts
Hardware
Fig. 20.1
2 x Roof Spacer FSC 5/4 x 6 x 32-1/4”
200
1 x #8 x 3” Wood Screw
S4
Step 20: Roof Spacer Assembly
A: Attach 1 (200) Roof Spacer to another at the peak using 1 (S4) #8 x 3” Wood Screw. Notice the pilot holes
are towards the bottom of the board. (g. 20.1)
B: Make sure the assembly is square.
Notice hole position.
200
S4
