Cedar Summit F25650 - Crowsnest Assembly

A: Loosely attach (160) Crowsnest Top ush to the top of 2 (161) Crowsnest Posts, noticing the bolt holes are at
the top, with 2 (WB7) 5/16 x 3” Wafer Bolts (with at washer and t-nut). (g. 16.1, 16.2 and 16.3)
B: Loosely attach 1 (162) Crowsnest Side ush to the top of each (161) Crowsnest Posts with 2 (WB9) 5/16 x
2-1/8” Wafer Bolts (with at washer and t-nut). (g. 16.1, 16.2 and 16.3)
Fig. 16.1
Step 16: Crowsnest Assembly
Part 1
Hardware
2 x 5/16 x 3” Wafer Bolt (5/16”atwasher,5/16”t-nut)
2 x 5/16 x 2-1/8” Wafer Bolt (5/16”atwasher,5/16”t-nut)
WB7
5/16” T-Nut (hidden)
5/16” Flat
Washer
Top View
160
Fig. 16.2
Fig. 16.3
5/16” T-Nut
5/16” Flat
Washer
162
162
161
161
1 x Crowsnest Top FSC 5/4 x 5 x 37-7/8”
2 x Crowsnest Post FSC 2 x 3 x 28”
2 x Crowsnest Side FSC 5/4 x 5 x 16-3/4”
Wood Parts
160
161
162
WB9
WB7
WB9
WB9
160
162
162
161
161
