Cedar Summit F25650 - Page 56

4 x #12 x 3/4” Pan Screw
Hardware
1 x Flat Panel Bracket
Other Parts
S8
Fig. 10.6
Step 10: Back Wall Assembly
Part 3
E: On the inside of the assembly attach (050) Narrow Window Panel to (060) Half Narrow Window Panel using 1
Flat Panel Bracket with 4 (S8) #12 x 3/4” Pan Screws. (g. 10.6 and 10.7)
Flat Panel Bracket
Fig. 10.7
S8
050
060
Front
Back
