F: From inside the assembly attach (190) Right Gable Angle to (050) Narrow Window Panel and (191) Left
Gable Angle to (040) Cafe Wall Window Panel using 1 Corner Panel Bracket with 3 (S13) #6 x 5/8” Pan Screws
per side. (g. 23.5)
6 x #6 x 5/8” Pan Screw
Other Parts
2 x Corner Panel Bracket
050
Step 23: Attach Roof Support Assemblies
Part 3
Fig. 23.5
x 3 per bracket
190
191
S13
040
Flush
S13
Corner Panel Bracket
(right one hidden)
