Cessna 182 - PART 4 - OPERATING DATA AND LIMITATIONS

4-1
PART 4
OPERATING DATA AND LIMITATIONS
GENERAL
1. The operating parameters detailed in Part I provide for the safe and optimum operation
of the aircraft. Except in an emergency, these limitations shall be observed.
GENERAL DATA
2. The following general data apply:
Fuel
Acceptable Grades
100 LL
Minimum Takeoff Fuel
EDM 930 Totalizer
15 USG
Fuel Tank Gauges Total
20 USG
Oil
Acceptable Grades
Journey Log
Max Capacity
12 US Qts
Top Up if below
10 US Qts
Min Level for Take-Off
9 US Qts
Tire Pressures
Main Wheel
30 psi
Nose Wheel
30 psi
Allowable Flap Settings
Take-Off
0 – 20º
Landing
0 - 35º
Nose Oleo
Normal Extension
2-4 inches
Vortex Generators
Maximum Number Missing
5
Shock Cooling
Threshold CHT Cooling Rate
60º / min
Fly Over Noise Level (ref D)
Max Continuous Power
81.9 dB (A)
Tow Hook Capacity (ref X)
Max Rated Load
2200 lbs
Figure 4-1 General Data
