Cessna 182 - Scanner Display; Remote Auxiliary Display (RAD)

1-35
Scanner Display
64. The Scanner Display portion of the screen on the bottom left hand side of the display
can be used to display pilot selectable parameters, including the following:
Display Parameter
Typical Display
Exhaust Gas Temperature
1354 EGT
Cylinder Head Temperature
375 CHT
Fuel Remaining (USG)
33.4 REM
Fuel Used Since Reset
24 USD
Fuel Time to Empty
02:45 H:M
Rate of Shock Cooling
-30 CLD
Max Difference between EGTs
80 DIF
Figure 1-42 Scanner Display Parameters
Remote Auxiliary Display (RAD)
65. A Remote Auxiliary Display (RAD) using LEDs is mounted on the upper left hand side of
the instrument panel. During normal operations, the RAD will display a secondary indication of
Propeller RPM and Manifold Pressure. When an alert is triggered, the RAD will flash and
display the nature of the alert. The RAD must be functioning for the aircraft to be airworthy.
Figure 1-43 Remote Auxiliary Display
