Cessna 182 - Lighting Systems; Exterior Lighting

1-41
LIGHTING SYSTEMS
Exterior Lighting
75. Conventional navigation lights are installed in the wing tips and tail cone. Anti-collision
strobe lights are mounted on the wing tips. A high intensity LED anti-collision light is mounted
on top of the vertical stabilizer. High intensity LED anti-collision pulse lights are mounted in the
wing leading edges at the tips, and dual high intensity LED taxi / landing lights are mounted in
the lower nose cowling. All are controlled by switches on the pilot’s lower instrument panel.
High Intensity LED Taxi / Landing Lights
High Intensity LED Pulse Light
Navigation Light
Strobe Light
High Intensity LED Strobe Light
Navigation Light
Figure 1-49 Exterior Lights
