Cessna 182 - Main Display

1-34
Main Display
63. The main display screen of the EDM930 is configurable. For normal operations, the
EDM930 display configuration will be as shown below:
Figure 1-40 Main Display
Display Parameter
Identifier
Notes
Propeller RPM
RPM
Manifold Pressure
MANIFOLD PRESSURE
Exhaust Gas Temperature
EGT
Cylinder Head Temperature
CHT
Oil Temperature
OIL-T
Oil Pressure
OIL-P
Fuel Pressure
FUEL-P
Fuel Remaining
FUEL REM
Calculated parameter
Ammeter
AMPS
Voltmeter
VOLTS
Fuel Flow Rate
FUEL FLW
Fuel Quantity
FUEL QTY
Outside Air Temperature
OAT
Percent Brake Horsepower
%HP
Figure 1-41 Display Parameters
