1-10
13. Rear passenger seats consist of a fixed one-piece seat bottom with individually
adjustable seat backs. To adjust either seat back, lift the adjustment lever on the outside
bottom corner of the seat back and reposition the seat back. Seat backs should not be adjusted
in flight.
14. The pilot seats are equipped with a four point harness with a rotary buckle and non-
lockable inertia reel on the shoulder harnesses. The rear seats are equipped with a three point
harness with a non-lockable inertia reel on the shoulder harness.
15. A baggage compartment is located behind the rear seats. Cargo tie-down rings are
provided to secure items in the compartment. Refer to Part 4 Figure 4-19 for specific weight
limits in the baggage compartment. The baggage compartment is accessible either over the
rear seat, or through an external door on the left hand side of the fuselage. The baggage door
is fitted with a locking latch mechanism.
Ensure that all items carried in the baggage compartment are
properly secured prior to flight.
To prevent inadvertent opening in flight, the baggage door must be
locked prior to flight.
16. A removable ballast block weighing 20 lbs is installed in the aft baggage compartment to
optimize the centre of gravity position for normal operations. The ballast block is contained in a
metal box mounted to the floor of the baggage compartment, and is secured using a pip pin.
The ballast block can be removed when the aircraft is heavily loaded, or is loaded towards the
rear centre of gravity limit.
