2.2 Information of CG Product Model
2.2.1 Information of CG General Drive
Table 2-1 VS Series General Product model and technical data
Model No.
Power capacity KVA
Rated
Input
current
A
Rated output
current
A
Applicable motor
kW
HP
VSX Series 3-Phase:415V，50/60Hz Range:-20%～+20%
VSX48-003-20CEB
1.5
3.4
2.5
0.75
1
VSX48-004-20CEB
3
5.0
4.2
1.5
2
VSX48-006-20CEB
4
5.8
5.5
2.2
3
VSX48-009-20CEB
6
11
9.5
3.7, 4
5
VSX48-013-20CEB
8.9
14.6
13
5.5
7.5
VSX48-017-20CEB
11
20.5
17
7.5
10
VSX48-024-20CEB
17
26
25
11
15
VSX48-032-20CEB
21
35
32
15
20
VSX48-038-20CEB
24
38.5
37
18.5
25
VSX48-045-20CEB
30
46.5
45
22
30
VSM Series 3-Phase:415V，50/60Hz Range:-20%～+20%
VSM48-003-20CEB
1.5
3.4
2.5
0.75
1
VSM48-004-20CEB
3.0
5.0
4.2
1.5
2
VSM48-006-20CEB
4.0
5.8
5.5
2.2
3
VSM48-009-20CEB
6.0
11
9.5
3.7, 4
5
VSS Series 1-Phase:220V，50/60Hz Range:-20%～+20%
VSS23 2p5 CEB
1.0
6.5
2.5
0.37,0.4
0.5
VSS23 4p2 CEB
1.5
9.3
4.2
0.75
1.0
VSS23 5p5 CEB
2.0
11
5.5
1.1
1.5
VSS23 7p5 CEB
3.0
15.7
7.5
1.5
2
VSS23 9p5 CEB
4.0
24
9.5
2.2
3
2.2.2 Information of CG Solar Drive
Table 2-2 VSR Series Product model and technical data
Model No.
Recommende
d Solar Array
Power kWP
Maximum
Input DC
Current A
Output
Current A
Motor kW
Frame
Size
VSR11 Series: 110VAC/160VDC input
VSR119p5
1.1
18
9.5
0.75
VSR2
VSR23 Series: 220VAC/310VDC input
VSR232p5
0.6
4.5
2.5
0.37, 0.4
VSR1
VSR234p2
1.1
7.5
4.2
0.75
VSR237p5
2.25
10
7.5
1.5
VSR2
VSR239p5
3.3
18
9.5
2.2
VSR48 Series:415VAC/540VDC input
VSR48003
1.1
4.5
2.5
0.75
VSR2
VSR48004
2.25
7.5
4.2
1.5
VSR48006
3.3
10
5.5
2.2
VSR48009
6
18
9.5
3.7, 4
VSR3
VSR48013
8.25
20
13
5.5
VSR48017
11
30
17
7.5
