Group U0 Status Monitoring
Group U0 is used to monitor the AC drive's running state. You can view the parameter values by
using keypad, convenient for on-site commissioning, or from the host computer by means of
communication (address: 0x3000～0x3020). Status monitoring parameters in the running and stop
state are defined by L0.03 and L0.103.
U0.00
Running frequency
Range:0.00～Fup
Default:0.00Hz
U0.01
Set frequency
Range:0.00～Fmax
Default:0.00Hz
U0.02
Output voltage
Range:0～660V
Default:0V
U0.03
Output current
Range:0.0～3000.0A
Default:0.0A
U0.04
Output power
Range:-3000.0～3000.0kW
Default:0.0kW
U0.05
Estimated Motor Speed
Range:0～60000rpm
Default:0rpm
U0.06
Bus voltage
Range:0～1200V
Default:0V
U0.07
Synchronous
Frequency
Range:0.00～Fup
Default:0.00Hz
U0.08
PLC step
Range:1～15
Default:1
U0.09
Program Operation
Time
Range:0.0～6000.0s(h)
Default:0.0s(h)
U0.10
PID set
Range:0～60000
Default:0
U0.11
PID feedback
Range:0～60000
Default:0
They display the PID setting value and PID feedback value.
PID setting = PID setting (percentage) * F0.03
PID feedback = PID feedback (percentage) * F0.03
U0.12
Status of DI1～DI5
digital input terminal
Range:00000～11111
Default:00000
0 means terminal input status is OFF, while 1 means terminal input status is ON.
Unit's place: DI1
Ten’s place: DI2
Hundred’s place: DI3
Thousand’s place: DI4
Ten Thousand’s place: DI5 (VSX Only)
U0.13
Status of DI6～AI3
digital input terminal
Range: 00000～11111
Default: 00000
0 means terminal input status is OFF, while 1 means terminal input status is ON.
Unit's place: DI6 (VSX Only)
Ten’s place: DI7 (VSX Only)
Hundred’s place: AI1
Thousand’s place: AI2
Ten Thousand’s place: AI3 (VSX Only)
U0.14
Status of digital output
terminal
Range: 0000～1111
Default: 0000
0 means terminal input status is OFF, while 1 means terminal input status is ON.
Unit's place: Y1
Ten’s place:Y2 (VSX Only)
Hundred’s place: R1
Thousand’s place: R2 (VSX Only)
U0.15
AI1 input
Range: 0.0～100.0%
Default: 0.0%
U0.16
AI2 input
Range: 0.0～100.0%
Default: 0.0%
U0.17
AI3 input
(VSX Only)
Range: 0.0～100.0%
Default: 0.0%
U0.18
Keypad potentiometer
input
Range: 0.0～100.0%
Default: 0.0%
U0.19
HI input
Range: 0.00～100.00kHz
Default: 0.00kHz
U0.20
AO1 output
Range: 0.0～100.0%
Default: 0.0%
U0.21
AO2 output
Range: 0.0～100.0%
Default: 0.0%
