CG VSR239p5 - Technical Features

Emotron VS Series Quick Start Guide
- 10 -
2.3 Technical Features
2.3.1 Features of General Drive
Table 2-3 Technical features of general drive
Project
Specifications
Power input
Rated input
voltage (V）
3-phase 415 V (-20%～+20%)
1-phase 220V (-20%～+20%)
Rated input
current (A）
See table 2-1
Rated input
frequency（Hz）
50Hz/60Hz，tolerance±5%
Power output
Applicable motor
（kW）
See table 2-1
Rated output
current（A）
See table 2-1
The maximum
output voltage
（V）
0～rated input voltage, error<±3%
The maximum
output frequency
（Hz）
0.00～600.00 Hz,unit0.01Hz
Control
characteristics
V/f patterns
V/f control
Sensor-less vector control 1
Sensor-less vector control 2
Speed range
1:50 (V/f control)
1:100 (sensor-less vector control 1)
1:200（sensor-less vector control 2）
Speed accuracy
±0.5% (V/f control)
±0.2% (sensor-less vector control 1 & 2)
Speed
fluctuation
±0.3% (sensor-less vector control 1 & 2)
Torque response
< 10ms (sensor-less vector control 1 & 2)
Starting torque
0.5Hz: 180% (V/f control, sensor-less vector control 1)
0.25Hz: 180% (sensor-less vector control 2)
Basic functions
Carrier
frequency
0.7kHz～16kHz
Overload
capability
G Model:150% Rated Current 60s,180% Rated Current
10s,200% Rated Current 1s.
P Model:120% Rated Current 60s,145% Rated Current
10s,160% Rated Current 1s.
Torque boost
Automatic torque boost；Manual torque boost 0.1%～30.0%
V/F Curve
Three ways: Three ways: straight; multi-point type; N
Th-type V / F curve（1.2 Th -type, 1.4 Th -type, 1.6 Th -type,
1.8 Th -type, 2 Th -type）
Acceleration and
deceleration
Curve
Line or curve acceleration and deceleration mode.
Four kinds of acceleration and deceleration time，Ramp
Time Range :0.0～6000.0s
DC brake
DC brake start frequency: 0.00～600.00Hz
DC brake time:0.0s～10.0s
DC brake current:0.0%～150.0%
Basic functions
Jog brake
Jog frequency range:0.00Hz～50.00Hz.
Jog deceleration time: 0.0s～6000.0s.
Simple PLC,
Multi-speed
Through the built-in PLC or control terminal to achieve up to
16 speed running
Built-in PID
Facilitate the realization of process control loop control
system
