H0.08
Group U0.00 output
frequency numerical attribute
Range: 0～1
Default: 0
0:Positive and negative value （Forward: Positive value，reverse: negative value）
1: Absolute value
Group L0 Keys and Display of Keypad Parameters
L0.00
MF.K key setting
Range:0～4
Default:0
0: No function
1: Jog
2: Forward/reverse switchover
3: local/ Remote selection
4:Jog reverse
L0.01
Function of STOP/RST key
Range:00～11
Default:01
L0.11
Speed display coefficient
Range:0.00～100.00
Default: 1.00
Unit’s place: STOP/RST key function
0: STOP/RST key valid only when under keypad control
1: STOP/RST key valid under any run command source
Ten’s place: speed display(the value of U0.05)
0:Display the speed estimated
1:Display the value(frequency multiply by speed display coefficient L0.11)
L0.02
Keys locked option
Range:0～4
Default:0
0: Not locked
1: Full locked
2: Keys locked other than RUN, STOP/RST
3: Keys locked other than STOP/RST
4: Keys locked other than >>
L0.03
LED displayed parameters
setting 1 on running status
Range:0～99
Default:0
L0.04
LED displayed parameters
setting 2 on running status
Range:0～99
Default:6
L0.05
LED displayed parameters
setting 3 on running status
Range:0～99
Default:3
L0.06
LED displayed parameters
setting 4 on running status
Range:0～99
Default:2
Sets LED displayed parameters on running status. When a number of parameters are selected to
be displayed, skim- through could be performed using key >> on keypad. 0～99 corresponding
U0.00～U0.99.
L0.07
LED displayed parameters
setting 1 on stop status
Range:0～99
Default:1
L0.08
LED displayed parameters
setting 2 on stop status
Range:0～99
Default:6
L0.09
LED displayed parameters
setting 3 on stop status
Range:0～99
Default:15
L0.10
LED displayed parameters
setting 4 on stop status
Range:0～99
Default:16
Sets LED displayed parameters on stop status. When a number of parameters are selected to be
displayed, skim-through could be realized via key >> on keypad. 0～99 corresponding U0.00 ～
U0.99.
L0.12
Power display coefficient
Range: 0.0～300.0%
Default: 100.0%
The parameter is used to adjust the value of power displayed on keypad
L0.13
The enable difference range of
U0.00 and U0.01
Range: 0.00Hz～
5.00Hz
Default:0.10Hz
When the difference range of U0.00 and U0.01 is within the set value of L0.13, then the value of
U0.00 will be stable.
