3.4 Configuration of Peripheral Devices
+/PB
L1/L2/L3
U/V/W
power source
circuit breaker
contactor
Input chokes
Input filter
Braking
resistor
Output filter
Output AC
reactor
motor
Inverter
Fig 3-6 Standard configuration of peripheral device
