2.3 Wiring between VFD and motor(No need to remove capacitor)
Running direction of motor is determined by the attribute of motor.
(-) (+) PB
M
KM1
L1
L2
U
W
220VAC
V
VSR
Fig 7-12 wiring between VSR VFD and motor
After wiring is completed, set d0.00=3
