CG VSR239p5 - Page 16

Emotron VS Series Quick Start Guide
- 15 -
Table 2-7 Configuration, mounting dimensions and weight
Model NO.
External and installation dimensions（mm）
Weight
（Kg）
W
H
D
W1
H1
Mounting
Hole
Diameter
3-Phase:415V，50/60Hz Range:-20%～+20%
VSX48-003-20CEB
80
200
170
60
185
4.5
1.45
VSX48-004-20CEB
VSX48-006-20CEB
VSX48-009-20CEB
116.6
186.6
175
106.6
176.6
4.5
2.45
VSX48-013-20CEB
2.5
VSX48-017-20CEB
146
249
181.7
131
236
5.5
3.4
VSX48-024-20CEB
3.5
VSX48-032-20CEB
198
300
189.7
183
287
5.5
6.35
VSX48-038-20CEB
6.45
VSX48-045-20CEB
6.45
2.4.2 VSM Series
W
H
D
H1
W1
d1
H2
d2
H3
Fig 2-5 Product size
Table 2-8 Configuration, mounting dimensions and weight
Model.
External and Install dimensions (mm)
N.W
(kg)
W
H
D
W1
H1
H2
H3
Install
hole
d1
Install
hole
d2
VSM48-003-20CEB
75
150
117
65
140
35
38.5
4.5
4.5
0.85
VSM48-004-20CEB
VSM48-006-20CEB
93
171
130
82
160
35
39
4.5
4.5
1.45
VSM48-009-20CEB
