Emotron VS Series Quick Start Guide
- 29 -
3.6.2 Main Circuit Terminals of VSM
◆ a: Single-phase Main Circuit Terminals
Fig 3-13 Single-phase main circuit terminals
◆b: Three-phase Main Circuit Terminals
L1
L2 L3
U
V
W
POWER
MOTOR
PB
(+)
Fig 3-14 Three-phase Main Circuit Terminals
3.6.3 Main Circuit Terminals of VSS
Single-phase 0.4~2.2KW Main Circuit Terminals
L1 L2 U V W
(+) (-)
Fig.3-15 0.4～2.2kW main circuit terminals
3.6.4 Main Circuit Terminals of VSR
◆a: Single-phase 0.4~2.2KW Main Circuit Terminals
(Same with VSS)
◆b: Three-phase 415V 0.75~2.2KW Main Circuit Terminals
