Emotron VS Series Quick Start Guide
- 80 -
input terminal
U0.13
Status of DI6～DI7 digital
input terminal
DI7 DI6
00
⊙
U0.14
Status of digital output
terminal
R2 R1 Y2 Y1
0000
⊙
U0.15
AI1 input
0.0～100.0%
0.0%
⊙
U0.16
AI2 input
0.0～100.0%
0.0%
⊙
U0.17
AI3 input
(VSX Only)
-100.0～100.0%
0.0%
⊙
U0.18
Keypad potentiometer
input (VSM only)
0.0～100.0%
0.0%
⊙
U0.19
HI input
0.00～100.00kHz
0.00kHz
⊙
U0.20
AO1 output
0.0～100.0%
0.0%
⊙
U0.21
AO2 output
(VSX Only)
0.0～100.0%
0.0%
⊙
U0.22
HO output
(VSX Only)
0.00～100.00kHz
0.00kHz
⊙
U0.23
Temperature of inverter
-40.0℃～120.0℃
0.0℃
⊙
U0.24
Accumulative power-on
time
0～65535min
0min
⊙
U0.25
Accumulative running time
0～6553.5min
0.0min
⊙
U0.26
Cumulative power-on
time
0～65535h
0h
⊙
U0.27
Cumulative running time
0～65535h
0h
⊙
U0.28
Count value
0～65535
0
⊙
U0.29
Length value
0～65535m
0m
⊙
U0.30
Linear speed
0～65535m/min
0m/Min
U0.31
Output torque
0.0～300.0%
0.0%
⊙
U0.32
PTC motor temperature
detection
-40℃～200℃
0℃
⊙
U0.33
Speed that detected by
encoder
0～60000rpm
0rpm
⊙
U0.34
Monitoring of encoder line
number
0～65535
0
⊙
U0.35
Power consumption
0～65535kWh
0kWh
⊙
U0.36
VDI1～VDI5 input status
VDI5 VDI4 VDI3 VDI2 VDI1
00000
⊙
U0.37
VDO1～VDO5output
status
VDO5 VDO4 VDO3 VDO2 VDO1
00000
⊙
U0.38
High speed pulse X7 or the
line number of expansion
card monitoring
0～65535
0
⊙
Group U1 Fault Record
U1.00
Code of the latest fault
Err00: No fault
0
⊙
Err01: Accel overcurrent
Err02: Decel overcurrent
Err03: Constant-speed overcurrent
Err04: Accel overvoltage
Err05: Decel overvoltage
Err06: Constant-speed overvoltage
Err07: Bus undervoltage
Err08: Short circuit
Err09: Power input phase loss
Err10: Power output phase loss
Err11: Motor overload
