CG VSR239p5 - Page 99

Emotron VS Series Quick Start Guide
- 98 -
OFF
OFF
ON
ON
Reference 3
F1.03
OFF
ON
OFF
OFF
Reference 4
F1.04
OFF
ON
OFF
ON
Reference 5
F1.05
OFF
ON
ON
OFF
Reference 6
F1.06
OFF
ON
ON
ON
Reference 7
F1.07
ON
OFF
OFF
OFF
Reference 8
F1.08
ON
OFF
OFF
ON
Reference 9
F1.09
ON
OFF
ON
OFF
Reference
10
F1.10
ON
OFF
ON
ON
Reference
11
F1.11
ON
ON
OFF
OFF
Reference
12
F1.12
ON
ON
OFF
ON
Reference
13
F1.13
ON
ON
ON
OFF
Reference
14
F1.14
ON
ON
ON
ON
Reference
15
F1.15
Table 2 State combinations of two terminals for acceleration/deceleration time selection
Acceleration/Deceler
ation time
determinant 2
Acceleration/Deceler
ation time
determinant 1
Acceleration/Deceleratio
n Time Selection
Corresponding
Parameters
OFF
OFF
Acceleration/Deceleratio
n time 1
b2.00, b2.01
OFF
ON
Acceleration/Deceleratio
n time 2
b2.02, b2.03
ON
OFF
Acceleration/Deceleratio
n time 3
b2.04, b2.05
ON
ON
Acceleration/Deceleratio
n time 4
b2.06, b2.07
C0.10
Filtering time of digital
input terminal
Range:0.000～1.000s
Default:0.010s
Set the filtering time of DI1～DI7 (when DI7/HI is used as ordinary low-speed terminal), AI1, AI2
and AI3 (when used as digital input terminal). Interference immunity of digital input terminals can be
improved by appropriate filtering time. However, the response time of digital input terminal will become
slower when filtering time is increased.
ATTENTION:
This filtering time takes no effect on DI7/HI when DI7/HI terminal is used as DI high-speed input
terminal, while the filtering time of DI is determined by parameter C2.36.
C0.11
Delay time before terminal
DI1 is valid
Range:0.0～300.0s
Default:0.0s
C0.12
Delay time before terminal
DI2 is valid
Range:0.0～300.0s
Default:0.0s
C0.19
Delay time before terminal
DI1 is invalid
Range:0.0～300.0s
Default:0.0s
C0.20
Delay time before terminal
Range:0.0～300.0s
Default:0.0s
