13 610 02 1018
19
System Description
Therapeutically effective
penetration depth 5 MPa
0 - 65 mm
0 - 50 mm
0 - 35 mm
Depth of
focal zone
20 - 40 mm
5 - 25 mm
0 - 10 mm
0 mm
15 mm
30 mm
Fig. 3-6 Depth of therapeutical effect of C-ACTOR handpiece
• Perform changing of the stand-off devices as described in chapter 6.2.1 changing
the stand-Off device.
NOTE
The stand-off has a limited service life. It should be replaced if there are visible
changes in the material (discolouration, tarnishing, streaks, gas bubbles), defor-
mation of the surface in the coupling area or leaks.
The stand-off should be replaced at least every 12 months.
