Installation Instruction
4.5 Transport
NOTE
Make sure that your hands are dry and free of grease.
ATTENTION !
The side walls of the device can be bent if it is not transported correctly.
Defect of the touchscreen or other components!
• DO NOT carry the device by means of mounted accessory parts (e.g. F-SW
plug).
• Dismount the handpiece holder before transporting the device.
• To transport the instrument, grip the indentations on the side of the housing as
shown in the picture below (1) and lift it carefully.
1
Fig. 4-11 Transporting the device
• Set the device slantly down in order to avoid squeezing the ngers.
4.6 Compatibility
The Chattanooga Intelect F-SW is allowed to be operated with the following accesso-
ries:
– Handpiece F-SW SEPIA LT Art. no. 19000
– Handpiece C-ACTOR SEPIA LT Art. no. 29204.0001
– Foot switch
