Chattanooga Intelect Focus Shockwave - Setting the treatment parameters

13 610 02 1018
34
Operation
5.4 Setting the treatment parameters
Once the unit has been started, the display automatically shows the last setting.
• Touch the ashing parameter display or one of the parameter selection elds to
conrm the operating mode.
• Select the line of the parameter that you would like to change.
• Set the value using the arrow keys.
• Release shocks.
NOTE
The maximum possible frequency with which shock waves are generated depends
on the selected energy level (see tables below and next side). Increasing the
energy level may reduce the therapy wave frequency.
F-SW
EnergyuxdensityinmJ/mm
2
Maximum frequency Handpiece
0,55 3 Hz
0,50 3 Hz
0,45 3 Hz
0,40 3 Hz
0,35 4 Hz
0,30 4 Hz
0,25 4 Hz
0,20 5 Hz
0,15 6 Hz
0,12 6 Hz
0,10 6 Hz
0,07 6 Hz
0,05 7 Hz
0,03 8 Hz
0,02 8 Hz
0,01 8 Hz
Table 5 -1 Setting the treatment parameters in F-SW mode
