Connecting Two Quantum Maestro Orchestrators for Redundancy
Quantum Maestro Getting Started Guide|95
Step Device Instructions
2 On the first
Quantum
Maestro
Orchestrator
(15)
Perform these steps:
1. With cable (18), connect a Downlink port (in our example, Port 18)
to the applicable port on the first Security Appliance (30) in the
Security Group 1 (31).
2. With cable (20), connect a Downlink port (in our example, Port 22)
to the applicable port on the second Security Appliance (29) in the
Security Group 1 (31).
3. With cable (22), connect a Downlink port (in our example, Port 26)
to the applicable port on the first Security Appliance (27) in the
Security Group 2 (28).
4. With cable (24), connect a Downlink port (in our example, Port 30)
to the applicable port on the second Security Appliance (26) in the
Security Group 2 (28).
See these sections:
n
"Connecting cables between each Quantum Maestro Orchestrator
and ports on the Dual Port Card on each Security Appliance" on
page92
n
"Connecting cables between each Quantum Maestro Orchestrator
and 1 out of 4 ports on the Quad Port Card on each Security
Appliance" on page92
3 On the second
Quantum
Maestro
Orchestrator
(16)
Perform these steps:
1. With cable (19), connect a Downlink port (in our example, Port 18)
to the applicable port on the first Security Appliance (30) in the
Security Group 1 (31).
2. With cable (21), connect a Downlink port (in our example, Port 22)
to the applicable port on the second Security Appliance (29) in the
Security Group 1 (31).
3. With cable (23), connect a Downlink port (in our example, Port 26)
to the applicable port on the first Security Appliance (27) in the
Security Group 2 (28).
4. With cable (25), connect a Downlink port (in our example, Port 30)
to the applicable port on the second Security Appliance (26) in the
Security Group 2 (28).
See these sections:
n
"Connecting cables between each Quantum Maestro Orchestrator
and ports on the Dual Port Card on each Security Appliance" on
page92
n
"Connecting cables between each Quantum Maestro Orchestrator
and 1 out of 4 ports on the Quad Port Card on each Security
Appliance" on page92
4 On both
Quantum
Maestro
Orchestrators
(15 and 16)
Connect a DAC cable (17) between the dedicated synchronization port (in
our example, Port 32) on the first Quantum Maestro Orchestrator (15) and
the dedicated synchronization port (in our example, Port 32) on the
second Quantum Maestro Orchestrator (16).
Table: Workflow (continued)
