Board Components Shown in Figure 3.1
Item/callout from
Figure 3.1
Description
A Audio codec
B Front panel audio connector
C Ethernet device
D PCI Conventional bus add-in card connectors [2]
E PCI Express x16 bus add-in card connector
F Back panel connectors
G +12V power connector (ATX12V)
H Rear chassis fan connector
I LGA775 processor socket
J Intel 82945G GMCH
K Processor fan connector
L DIMM Channel A sockets [2]
M DIMM Channel B sockets [2]
N SCSI LED connector (optional)
O Legacy I/O controller
P Power connector
Q Diskette drive connector
R Parallel ATE IDE connector
S Battery
T Front chassis fan connector
U BIOS Setup configuration jumper block
V Serial ATA connectors [4]
W Auxiliary front panel power LED connector
X Front panel connector
Y Front panel USB connectors [2]
Z Chassis intrusion connector
AA Intel 82801G I/O Controller Hub (ICH7)
BB SPI flash device
CC IEEE-1394a controller (optional)
DD Front panel IEEE-1394a connectors (optional) [2]
EE Speaker
FF PCI Express x1 bus add-in card connector
