Manual 0-5186 3-5 Safety and Installation
SAFETY AND INSTALLATION WELDSKILL 250, 350
3.05 Environment
These units are designed for use in environments with increased hazard of electric shock.
A. Examples of environments with increased hazard of electric shock are:
1. In locations in which freedom of movement is restricted, so that the operator is forced to perform the work
in a cramped (kneeling, sitting or lying) position with physical contact with conductive parts.
2. In locations which are fully or partially limited by conductive elements, and in which there is a high risk of
unavoidable or accidental contact by the operator.
3. In wet or damp hot locations where humidity or perspiration considerable reduces the skin resistance of
the human body and the insulation properties of accessories.
B. Environments with increased hazard of electric shock do not include places where electrically conductive parts
in the near vicinity of the operator, which can cause increased hazard, have been insulated.
3.06 Location
Be sure to locate the welder according to the following guidelines:
• Inareas,freefrommoistureanddust.
• Ambienttemperaturebetween14°F(-10°C)to104°F(40°C).
• Inareas,freefromoil,steamandcorrosivegases.
• Inareas,notsubjectedtoabnormalvibrationorshock.
• Inareas,notexposedtodirectsunlightorrain.
• Placeatadistanceof12”(300mm)ormorefromwallsorsimilarthatcouldrestrictnaturalairowfor
cooling
• TheenclosuredesignofthispowersourcemeetstherequirementsofIP21SasoutlinedinAS60529.This
provides adequate protection against solid objects (greater than 12mm), and direct protection from vertical
drops. Under no circumstances should the unit be operated or connected in a micro environment that will
exceed the stated conditions. For further information please refer to AS 60529.
• Precautionsmustbetakenagainstthepowersourcetopplingover.Thepowersourcemustbelocatedona
suitable horizontal surface in the upright position when in use.
!
WARNING
Thermal Arc advises that this equipment be electrically connected by a qualified electrician.
3.07 Ventilation
Since the inhalation of welding fumes can be harmful, ensure that the welding area is effectively ventilated.
