WELDSKILL 250, 350 DISASSEMBLY pROCEDURE
Disassembly Procedure
2 Manual 0-5186
7.02 Control Board Removal
Read and follow safety information in Section 6.02 before proceeding with disassembly
Remove case (refer to 6.04) before remove control board.
Refer to graphics on page 7-3.
1. Disconnect CN1 harness from CN1 connector.
2. Disconnect CN2 harness from CN2 connector.
3. Disconnect CN3 harness from CN3 connector.
4. Disconnect CN4 harness from CN4 connector.
5. Disconnect CN5 harness from CN5 connector.
6. Disconnect CN6 harness from CN6 connector.
7. Disconnect CN7 harness from CN7 connector.
8. Disconnect CN8 harness from CN8 connector.
9. Disconnect CN9 harness from CN9 connector.
10. M4 screw,remove 4 screws from control panel.
Ensure to unplug all harness from the main control PCB.
