3.08 Mains Supply Voltage Requirements
The Mains supply voltage should be within ± 15% of the rated mains supply voltage. Too low a voltage may cause
poor welding performance. Too high a supply voltage will cause components to overheat and possibly fail.
The Welding Power Source must be:
• Correctlyinstalled,ifnecessary,byaqualiedelectrician.
• Correctlyearthed(electrically)inaccordancewithlocalregulations.
• ConnectedtothecorrectsizepowerpointandfuseaspertheSpecicationsonpage3-2,3-3and3-4.
The WeldSkill 250 MIG Power Source is supplied with a 20 Amp input lead and is designed for a 240 VAC supply
voltage.
The following Mains Current Circuit recommendations are required to obtain the maximum welding current and
duty cycle from these welding products:
Mains Supply
Voltage
Setting
Mains
Supply
Lead Size
Minimum
Mains
Current
Circuit Size
Machines
Duty Cycle
240V 2.5 mm
2
15 Amp 220 A @ 20%
240V 4 mm
2
25 Amp 250 A @ 25%
Table 3-4 WeldSkill 250 Supply Requirements
NOTE
Motor start fuses or thermal circuit breakers are recommended for this application. Check local
requirements for your situation in this regard.
The WeldSkill 350 MIG Power Source is supplied with a 15 Amp input lead and is designed for a 415 VAC supply
voltage.
The WeldSkill 350 MIG Power Source is suitable for below Mains supply voltages:
Mains Supply
Voltage
Setting
Mains
Supply Lead
Size
Minimum
Mains
Current
Circuit Size
Machines Duty
Cycle
415V 1.5 mm
2
15 Amp 350A @ 30%
Table 3-5 WeldSkill 350 Supply Requirements
NOTE
Motor start fuses or thermal circuit breakers are recommended for this application. Check local
requirements for your situation in this regard.
WARNING
Any electrical work must be carried out by a qualified Electrical Tradesperson.
