TROUBLESHOOTING WELDSKILL 250, 350
Manual 0-5186 6-3 Troubleshooting
6.04 Case Removal
!
Read and follow safety information in Section 6.02 before proceeding.
1. Cover
Remove Screws
Art # A-10152
1
- Remove all the screws from the cover panel
2. Door Panel
- Carefully lift the door panel from power source.
- Remove screws from the cover panel.
Remove Screws
Art # A-10153
2
