Cima PLUS - 2 Glossary; Terminology; Abbreviations; Decals

3-2012
Plus 42 - 45 - 50 - 55
3
2 GLOSSARY 2
2.1 - TERMINOLOGY
The terms FRONT, REAR, RIGHT and LEFT utilised in this publication refer to the sprayer as seen by
an operator from behind the operative unit along the drive line and facing it: the rear part of the machine
is that closest to the operator, and is where the distribution device (Head) is mounted - and the front
part is the one that gets attached to the tractor.
2.2 - ABBREVIATIONS
cm ..................................................................................................................................... centimetres
g ..................................................................................................................................................grams
h .................................................................................................................................................... hour
ha............................................................................................................................................. hectare
ha/h .......................................................................................................................... hectare per hour
l ..................................................................................................................................................... litres
l/h................................................................................................................................... litres per hour
l/min........................................................................................................................... litres per minute
kg ............................................................................................................................................kilogram
kg/cm
2
..................................................................... kilograms per square centimeter (atmosphere)
km..........................................................................................................................................kilometre
km/h .................................................................................................................... kilometres per hour
Lm...............................................................................................................................width in metres
m .................................................................................................................................................metre
Mesh .................................................................................................... N° of meshes per linear inch
Micron ................................................................................................................. 1/1000 of millimetre
mm...................................................................................................................................... millimetres
PTO.............................................................................................................................. power take-off
RPM ............................................................................................................................ revs per minute
s ..............................................................................................................................................seconds
2.3 - DECALS
The safety and use/maintenance decals are applied to the machine are described in the following paragraph.
Every decal is marked with its part number, in case it needs to be replaced.
The arrangement of the adhesives on the machine is shown in the following pictures.
