5 COUPLING MODALITIES 5
5.1 - HITCHING TO THE TRACTOR
Check that the tractor’s “permissible carried weight” and the “rear overhang allowed”
are compatible with the weight and dimensions of the fully loaded sprayer and complete
with equipment mounted for the treatment (see Paragraphs “3.1” - “4.4.1” and the
attached documentation).
The tractor’s power take-off (PTO), under all utilisation conditions, must provide a power
exceeding that absorbed by the sprayer.
The hitching has to be carried out on a plane surface with a suitable consistency, after
having checked that all the people not charged with the operation moved away, as well
as the children and the animals possibly present. The road circulation is exclusively
allowed in full observation of the rules in force in the country where the machine is to
be used, WITHOUT having loaded any chemical substances inside the tank.
EXECUTION:
1. Loosen the chains of the lifter arms.
2. Start the tractor and take the lifter’s arms to the level of the machine’s pins.
3. Stop the tractor and remove the key from the control panel.
4. Insert the toggle joints on the machine’s pegs, locking them with the clip pins.
5. Hook the 3
rd
-point rod from the tractor to the machine and securing it with the peg and the clip pin.
6. Screw the rod to set it into tension.
7. Start the tractor and hoist the sprayer until the 2 PTO are the same height.
8. Stop the tractor, remove the key from the control panel and make sure that no
one approaches the hydraulic controls of the lifter.
NEVER OPERATE OR STAND BENEATH THE MACHINE OR IN THE AREA THAT
COULD BE INVOLVED IN ITS SUDDEN LOWERING.
9. By acting on the 3
rd
-point rod, vertically align the sprayer. N.B.: block the 3
rd
-point rod with the
specific lock ring.
10. Block the coupling by tightening the chains of the hoister arms.
When the operation is completed the 2 drive outlets (PTO) must be positioned on the
same axis, both in vertical and horizontal direction.
Type of mounted sprayer PLUS
Pairing suggested for tractors of at least 42 45 50 55 55S 55E
CV
25 45 65 70 80 90
kW
18 33 48 52 58 66
