Cima PLUS - MACHINE STRUCTURAL ANALYSIS

Plus 42 - 45 - 50 - 55
3-2012
12
4 MACHINE’S STRUCTURAL ANALYSIS 4
The pictures indicate the position of the main components of the sprayer.
PUMP
LEVER TAP FOR
DUST PRODUCTS
MIXING
00299(2)
DELIVERY
FILTER
CENTRIFUGAL
FAN
TANK
DISTRIBUTION
DEVICE
(HEAD)
JOINING
ELBOW
ROTATING DISC
REGULATOR
MAIN FILLER (BP)
FRAME
HEAD
PROTECTION
RING
00677
00184
ELECTRICAL
DISTRIBUTOR
(for the models
where it is
foreseen)
RINSING
TANK
(for the models
where it is
foreseen)
3-WAY TAP
LEVER TAP FOR EXCLUSION
OF ADDITIONAL HYDRAULIC
AGITATION
(for the models where it is foreseen)
