Plus 42 - 45 - 50 - 55
3-2012
54
13 MAINTENANCE OPERATIONS 13
ALL OPERATIONS MUST BE CARRIED OUT WITH THE ENGINE SWITCHED OFF AND WITH
THE IGNITION KEY REMOVED FROM THE CONTROL PANEL.
The machine has to be periodically revised according to the country rules. The
inspections and the release of the certificate have to be made by special provided
structure of the country where the machine is used.
13.1 - LUBRICATION
(*) Versions with fan shaft support provided of sealed bearings without maintenance.
Carefully clean the greasing nipples and the oil filler in order to avoid that, during
lubrication, dirt might be introduced. In the case of intensive use of the machine,
reduce the lubrication intervals.
PLUS_003
FAN
BELT-TENSIONER
SUPPORT
FREE WHEEL
FAN SHAFT SUPPORT
(Excluding Plus 42, G11 U11 S11 and R13 versions)
350
300
250
200
150
100
50
00065
00065
00128
00130
00298
OIL
MAX
MIN
8h
CONTROLLARE
CHECK
CONTRÔLER
CONTROLAR
95079
