4. Close the faucets (P2) (or P15) by positioning the lever on “c.”
5. Connect the filler piping to the pump.
6. Re-open the faucets (P2) (o P15) (lever on "a").
7. Immerse the filter with the bottom-drawing valve in the water to be loaded.
The filter must always be below the level of the water to be loaded. The piping must never
be above the pump’s suction point and must never be excessively bent in the vertical
direction.
8. Through the secondary filler BS, pour approximately 15~20 litres of water into the tank: the quantity
must be sufficient to FILL the piping and ACTIVATE the pump to start the recycle.
9. Activate the power take off (PTO) and take it to a rotation speed of at least 500 RPM.
540
Use ONLY the PTO at 540 rpm. Engage the PTO with the engine of the tractor at
low speed and with maximum modularity, obtaining soft and progressive graft
and avoiding abrupt starts of the cardan shaft.
10. When the pump has started the circulation of the water poured, close tap (P2) (o P15) (lever on “c”)
to start up the filling.
11a. WITH MEDICINAL MIXTURES OR LIQUID PRODUCTS (WITHOUT MIXER DEVICE).
11a1 Pour the mixture of medicinal envisaged through the main filler (BP), together with the water
used to wash the canister of product and the tools used in the preparation.
11a2. Close the main filler (BP) of the tank.
11a3. After completing the filling, disengage the PTO
11a4. Close the tap (P6) setting the lever in position “c”.
11a5. Disconnect the filler piping and replace the stopper on the pump.
11a6. Open the faucet (P2) (or (p15) by putting the lever on position “a”
11a7. Open the tap (P6) setting the lever in position “a”
11b. WITH POWDER PRODUCTS: UTILISING THE MIXTURE DEVICE
11b1. Pour the dose of medicinal in powder form foreseen for each loading into the main filler (BP) of
the tank.
11b2. Close the main filler (BP) of the tank.
11b3. Open the cock (P12) (lever on “a”).
11b4. Wait for the filling to be completed.
11b5. Close the cock (P12) (lever on “c”).
11b6. Disengage the power take off (PTO).
11b7. Close the faucet (P6) (lever on “c”)
11b8. Disconnect the filler piping and replace the stopper on the pump.
11b9. Open the faucet (P2) (or (p15) by putting the lever on position “a”
11b10.Open the tap (P6) setting the lever in position “a”
12. Engage the Power Takeoff and move to the treatment place, keeping the Power Takeoff running
rate at least 500 RPM during all the way.
IN THE AREA OF THE TREATMENT
13. Disengage the power take off (PTO) and rest the machine on the ground.
14.
STOP THE TRACTOR AND REMOVE THE KEY FROM THE CONTROL PANEL.
15. Make sure that the fan is stopped. Hook the fan to the servo amplifier as indicated at point 8.1.b.
16. Start the tractor, always observing the safety norms.
