61
Update
The scanner can be configured to send data to a host computer wirelessly via the 3666
base, or to a notebook computer or PDA with Bluetooth
®
wireless technology. Upon
powering up, the scanner will be ready for establishing a WPAN connection.
To establish a connection via 3666 after reading “Set Connection” and “Serial No.” labels …
Interface Option Reference
Keyboard Wedge 2.3 Keyboard Wedge via 3666
RS-232 2.4 RS-232 via 3666
USB HID (307) 2.3 Keyboard Wedge via 3666
IBM 4683/4694 (346) 2.3 Keyboard Wedge via 3666
To establish a connection via Bluetooth
®
dongle after pairing…
Interface Option Reference
BT HID 2.1 BT HID
BT SPP 2.2 BT SPP Slave
Chapter 3
SETTING UP A WPAN CONNECTION
To Next Page
