When the echo test is ongoing, the details display as illustrated below.
SNR (dB)
T RSS (-dBm) NF (-dBm)
(Signal to Noise ratio) (Transmit Speed) (Received Signal
Strength Level)
(Noise Floor Level)
0 ~ 10
10 ~ 20
20 ~ 30
30 ~ 40
over 40
Very Poor
Poor
Fair
Good
Very
Good
1
2
5.5
11
6
9
12
18
24
36
48
54
Mbps
Mbps
Mbps
Mbps
Mbps
Mbps
Mbps
Mbps
Mbps
Mbps
Mbps
Mbps
0 ~ 60
60 ~ 75
over 75
Strong
Moderate
Weak
0 ~ 92
92 ~ 98
over 98
Strong
Moderate
Weak
