4.4.2.2.- Screen L12 (CONTRACT 1: CLOSURE 01)
This shows recorded information from contract 1 during the last closure. The screen
acts in the same way as the L11 screen, using Absolute or Incremental values.
Table 8 Absolute energy value codes for contract 1 closure 1
ABS (Absolute)
OBIS Without OBIS
kWh 1.18.1.01 ABSIMP T1 C1-C01
kWh 1.18.2.01 ABSIMP T2 C1- C01
kWh 1.18.3.01 ABSIMP T3 C1- C01
kWh 1.18.4.01 ABSIMP T4 C1- C01
kWh 1.18.5.01 ABSIMP T5 C1- C01
kWh 1.18.6.01 ABSIMP T6 C1- C01
kWh 1.18.0.01 ABSIMP TOTAL
C1- C01
Active energy for each tariff
period (if active), from the start
of measurement until the last
closure included in the total
(period 0)
1.18.x.01 where x = tariff
(period)
kvarh 1.58.1.01 ABSQ1 T1 C1- C01
kvarh 1.58.2.01 ABSQ1 T2 C1- C01
kvarh 1.58.3.01 ABSQ1 T3 C1- C01
kvarh 1.58.4.01 ABSQ1 T4 C1- C01
kvarh 1.58.5.01 ABSQ1 T5 C1- C01
kvarh 1.58.6.01 ABSQ1 T6 C1- C01
kvarh 1.58.0.01 ABSQ1 TOTAL
C1- C01
Q1 Reactive energy for each
tariff period (if active), from the
start of measurement until the
last closure included in the
total (period 0)
1.58.x.01 where x = tariff
(period)
Power Excesses 1.12.1.01 EXCES T1 C1- C01
Power Excesses 1.12.2.01 EXCES T2 C1- C01
Power Excesses 1.12.3.01 EXCES T3 C1- C01
Power Excesses 1.12.4.01 EXCES T4 C1- C01
Power Excesses 1.12.5.01 EXCES T5 C1- C01
Power Excesses 1.12.6.01 EXCES T6 C1- C01
Excesses from the last billing
period (if active)
1.12.x.01 where x = tariff
(period)
Maximums 1.16.1.01 MAXDEM T1 C1- C01
Maximums 1.16.2.01 MAXDEM T2 C1- C01
Maximums 1.16.3.01 MAXDEM T3 C1- C01
Maximums 1.16.4.01 MAXDEM T4 C1- C01
Maximums 1.16.5.01 MAXDEM T4 C1- C01
Maximums 1.16.6.01 MAXDEM T6 C1- C01
L12
Maximums 1.16.0.01 MAXDEM TOTALC1-
C01
Maximums from the last billing
period (if active) included in the
total
1.16.x.01 where x = tariff
(period)
