4.- DISPLAY.
The different menus and/or screens may be displayed by using the key on the
CIRWATT. Pressing the
key, for less than 2 seconds (short press), moves through
the different active menus on the screen. Pressing the same key (
) for two seconds
(long press), automatically accesses the different secondary options and menus.
09-09-2003 12:23:10
Q1 1+2+3+ T534 NBC
Línieas de fase
activas
Quadrante Alarmas
Tarifas activas
Sentido
energía
Data is displayed via a one line LCD display especially designed for the CIRWATT.
The units and resolution of the energy values are the same as the overflow values in
the meter, i.e. they are the recorder’s values. The units will be kWh or kvarh. The size
of the records will be 8 whole digits (99.999.999)
The units in which any power and energy data is transmitted by the communications
protocol will be kW, kWh, and/or kvarh, independent of what is being displayed.
4.1.- Display Modes.
CIRWATT has different display modes representing different information.
4.1.1.- STAND BY Mode
This will always occur as a default, whenever the READING mode is not activated by
pressing or the key not being pressed for 60 seconds even though a menu has been
entered.
4.1.2.- READING Mode
This is activated by a long press on the
key, and displays the different options to
access data screens or other secondary menu screens. Pressing the
key (short
press) moves through the menu, a long press (pressing the
key for 2 seconds)
enters the option that is flashing on the screen. 60 seconds after the last press, the
Display returns to STAND BY Mode. The different values displayed on this screen are
shown in point 4.4 READING screens mode.
Quadrant
