Page no. 19
4.4.6.4.- Screen L44 (INFORMATION : INSTANT VALUES)
This screen shows information on the instant values of different electrical magnitudes.
As this data does not correspond to any specific contract but is data general to all, field
B will have the value 0.
Table 17 Screen L44. Instant values
Code
Screen
V3 VOL
VOLTAGE PER PHASE: This shows the
instant Voltage values in each phase
0.317.0
I3 AMP
CURRENT PER PHASE: This shows the
instant Current values in each phase
0.337.0
COS Φ PER PHASE: This shows the instant
values of cos Φ in each phase
0.17.0 P kW
INSTANT ACTIVE POWER: This shows the
instant Active Power in each phase with its
sign
0.37.0 Q kvar.
INSTANT REACTIVE POWER: This shows
the instant Reactive Power in each phase with
its sign
L44
INSTANT
FP 3F
AVERAGE POWER FACTOR: This shows the
average instant Power Factor in the three
phases
4.4.6.5.- Screen L45 (INFORMATION: COMMUNICATIONS)
This screen shows information on the different parameters of the communications
ports. As this data does not correspond to any specific contract but is data general to
all, field B will have the value 0.
Table 18 Screen L45. Communications
Code
Screen Text
OBIS No OBIS
Comments
0.00.0
OPTICO
SETTING THE OPTICAL SERIES
PORT: 000000n (009600 speed, n
parity)
0.00.1
R1
SETTING THE ELECTRICAL SERIES
PORT 1 OR ETHERNET: 000000n
(009600 speed, n parity)
0.00.2
R2
SETTING THE ELECTRICAL SERIES
PORT 2 OR ETHERNET: 000000n
(009600 speed, n parity)
L45
COMMUNICA-
TIONS
0.00.3
MODEM
START UP MODE FOR THE
ELECTRICAL SERIES PORT 1: It will
appear as data for the ASDU 142 of
the protocol
To Next Page
