Screens Text Comments
L43 CURRENT VALUES
This shows information on current power,
maximum demand, totals and power from the last
integration period (15 minutes as a default).
L44 INSTANT VALUES
This shows information on the instant values of
different electrical magnitudes.
L45 COMMUNICATIONS
This shows information on the different
parameters of the communications ports.
L46 IDENTIFIERS
This shows information on the equipment's
different identifiers, included those for the
IEC870-5-102 protocol.
L47
OUTPUT
CONSTANTS
This shows information on the output impulse
values.
L48 TIME CHANGE
This shows information on the dates of the time
change.
L49 BACK Returns to the previous screen.
4.4.6.- Screen L40 (INFORMATION: INDICATORS)
This screen shows information on the operating indicators. It is used to check the
proper working of the equipment in all its main areas during installation or during later,
on site checks. It is a DATA screen
As these indicators do not belong to a specific contract, but are general data, field B
has the value 0.
Table 13 Screen L40. Indicators.
Code
Screen Text
OBIS No OBIS
Comments
0.13.38
p.ej. 1
C.ACT
ACTIVE QUADRANT: This indicates the
direction of the active or reactive energy or
quadrant (1,2,3 or 4)
e.g. 0.13.38 1 shows that it is in quadrant 1
0.12.38
p.ej. 123
PRES.V
PRESENCE OF VOLTAGE: This indicates
the presence of voltage in each phase
(123 if there is voltage in all, blank if they
do not have voltage)
0.11.38
p.ej. 120
SENT.I
CURRENT DIRECTION: This indicates the
direction of importation (+) or exportation (-
) in each phase (111 if they are imported,
222 if exported, 000 if there is none)
0.18.128
p.ej. 633
TAR.AC
ACTIVE TARIFF FOR EACH CONTRACT:
This indicates the active tariff at the time of
reading for each contract (contract 1,
contract 2, contract 3)(values form 1 to 9
for each contract
e.g.:. 633
0.96.2.4
p.ej. 0
MODO ‘P
PARAMETERISATION MODE: This
indicates if the parameterisation mode is
enabled (0 disabled, 1 enabled)
L40
INDICATORS
0.96.5.0
p.ej. cnb
ALARMA
ALARMS This indicates the alarms defined
in section 4.3. The data field will display
the letters CNB, which will become active
according to the type of alarm.
