Page no. 20
4.4.6.6.- Screen L46 (INFORMATION: IDENTIFIERS)
This screen shows information on the equipment's different identifiers, including those
for the IEC870 protocol. As this data does not correspond to any specific contract but is
data general to all, field B will have the value 0.
Table 19 Screen L46. Identifiers
Code
Screen Text
OBIS No OBIS
Comments
0.00.5
D.REG LINK ADDRESS
0.00.6
DIR.PM MEASURING POINT ADDRESS
0.00.7
PROTOC
DATE OF THE COMMUNICATIONS
PROTOCOL VERSION: (DD-MM-YY),
data from the ASDU 142 of the
protocol will be shown
0.02.0
FIRMWA
EQUIPMENT'S FIRMWARE
VERSION: data from the ASDU 142
of the protocol will be shown
0.08.4
PINTG1
INTEGRATION PERIOD OF THE
FIRST LOAD CURVE: this shows the
integration period in minutes, 60
minutes as a default
L46
IDENTIFIERS
0.08.5
PINTG2
INTEGRATION PERIOD OF THE
SECOND LOAD CURVE: this shows
the integration period of the second
load curve in minutes, 15 minutes as
a default
4.4.6.7.- Screen L47 (INFORMATION: OUTPUT CONSTANTS
This screen shows information on the impulse values of the outputs. As this data does
not correspond to any specific contract but is data general to all, field B will have the
value 0.
Table 20 Screen L47. Output constants.
Screen.
Values
0.03.3 SAL. 1
0.03.4 SAL. 2
0.03.5 SAL. 3
L47
OUTPUT
CONST.
0.03.6 SAL. 4
Ax Y : x = 1:imported active |
x = 2 : exported active
Y = impulse weight
x Y : x= No. of quadrant (reactive
quadrant x
Y = impulse weight
Pow : Power demand meter
CxPy : x = Contract No.
y = tariff period No. (The output indicates
the tariff)
