Page no. 14
Data is displayed with zeros to the left to fill up the length of the data field display.
• For example: 2.18.2.01 Absolute active energy consumed, from period
2,penultimate bill closure from contract 2.
4.4.3.3.- Screen L23, L24, L25, L26, L27 (CONTRACT 2: CLOSURES 02 TO 06)
This shows recorded information on values from contract 2 from the closures prior to
the last closure. It acts in the same way as screens L13 L17 changes the group B code
from 1 to 2.
4.4.4.- Screen L3 (CONTRACT 3, SALE)
This screen accesses information on contract 3. It acts the same as screen L11,
however the codes change according to the Table 1 Display Codes page 5.
4.4.4.1.- Screen L3-L37 (CONTRACT 3: CURRENT AND CLOSURES 01 TO 06)
Shows information on values recorded for contract 3. A sample screen 31 is shown
below:
Table 10 Absolute values screen for contract 3 closure 1
AbS (Absolute)
OBIS Without OBIS
kWh 3.28.1 ABSEXP T1 C3-ACT
kWh 3.28.2 ABSEXP T2 C3-ACT
kWh 3.28.3 ABSEXP T3 C3-ACT
kWh 3.28.4 ABSEXP T4 C3-ACT
kWh 3.28.5 ABSEXP T5 C3-ACT
kWh 3.28.6 ABSEXP T6 C3-ACT
kWh 3.28.0 ABSEXP TOTAL C3-
ACT
Tariff periods for Active Energy
from the start of measurement
(if active), included in the total
3.28.x where x = tariff (period)
kvarh 3.68.1 ABSQ2 T1 C3-ACT
kvarh 3.68.2 ABSQ2 T2 C3-ACT
kvarh 3.68.3 ABSQ2 T3 C3-ACT
kvarh 3.68.4 ABSQ2 T4 C3-ACT
kvarh 3.68.5 ABSQ2 T5 C3-ACT
kvarh 3.68.6 ABSQ2 T6 C3-ACT
kvarh 3.68.0 ABSQ2 TOTAL C3-ACT
Tariff periods for Q2 Reactive
Energy from the start of
measurement (if active),
included in the total
3.68.x where x = tariff (period)
Power Excesses 3.22.1 EXCES T1 C1- C01
Power Excesses 3.22.2 EXCES T2 C1- C01
Power Excesses 3.22.3 EXCES T3 C1- C01
Power Excesses 3.22.4 EXCES T4 C1- C01
Power Excesses 3.22.5 EXCES T5 C1- C01
Power Excesses 3.22.6 EXCES T6 C1- C01
Excesses from the last billing
period (if active)
1.12.x.01 where x = tariff
(period)
Maximums 3.26.1 MAXDEM T1 C3-ACT
Maximums 3.26.2 MAXDEM T2 C3-ACT
Maximums 3.26.3 MAXDEM T3 C3-ACT
Maximums 3.26.4 MAXDEM T4 C3-ACT
Maximums 3.26.5 MAXDEM T5 C3-ACT
Maximums 3.26.6 MAXDEM T6 C3-ACT
L31-
L37
Maximums 3.26.0 MAXDEM TOTAL C3-
ACT
Maximums from the bill closure
(if active), included in the total
3.26.x where x = tariff (period)
