4.4.6.8.- Screen L48 (INFORMATION: TIME CHANGE)
This screen shows information on the dates of the time changes. As this data does not
correspond to any specific contract but is data general to all, field B will have the value 0.
Table 21 Screen L48. Time changes.
Code
Screen Text
OBIS
Sin
OBIS
Comments
0.00.8
I - V
WINTER-SUMMER TIME CHANGE: DD/MM/YY HH:MM
L48
TIME
CHANGE
0.00.9
V – I
SUMMER-WINTER TIME CHANGE: DD/MM/YY HH:MM
4.4.7.- Screen L5 (Manu Info)
4.4.7.1.- Model:
This screen identifies the model of the equipment. (See section 2.-METER MODEL).
CIRWATT v1.5b
410-UT5C-15C-00
4.4.7.2.- Series Number
This screen identifies the series number of the equipment.
NUMERO DE SERIE
342336001
4.4.7.3.- Date of Manufacture
This screen identifies the date of manufacture of the equipment.
FECHA DE FABRICACION
03-09-03
4.4.7.4.- Installation Screen
This screen supplies a reading of the values measured by the CIRWATT and therefore
allows a quick check to see if the equipment is properly installed.
V1:230 V2:230 V3:230
I1:2+I2:2+I3:2+ 50HZ
4.4.7.5.- CIRWATT Status
This screen shows the status of the equipment. In the event of a critical alarm going off,
the origin of the fault will be shown. For example a voltage fault in phase 3.
ESTADO CIRWATT
FUNCIONAMIENTO OK!
SERIES NUMBER
DATE OF MANUFACTURE
CIRWATT STATUS
OPERATION OK!
