Page no. 29
C.- Quadrants
Below is a chart showing the power sign and its corresponding energy quadrant used
by the CIRWATT meter.
1
st
Quadrant
4
th
Quadrant
3
rd
Quadrant
2
nd
Quadrant
Active
generated
Active
consumed
1
st
Quadrant
2
nd
Quadrant
3
rd
Quadrant
4
th
Quadrant
Reactive
generated
Reactive
consumed
