The codes for the incremental value variables are shown below:
Table 11Incremental values screen for contract 3 closure 1
Inc (Incrementales)
OBIS SIN OBIS
kWh 3.29.1
ABSEXP T1 C3-ACT
kWh 3.29.2
ABSEXP T2 C3-ACT
kWh 3.29.3
ABSEXP T3 C3-ACT
kWh 3.29.4
ABSEXP T4 C3-ACT
kWh 3.29.5
ABSEXP T5 C3-ACT
kWh 3.29.6
ABSEXP T6 C3-ACT
kWh 3.29.0
ABSEXP TOTAL C3-ACT
Consumption per Active Energy tariff
periods from the last billing period (if
active), included in the total
3.29.x.01 where x = tariff (period)
kvarh 3.69.1
ABSQ2 T1 C3-ACT
kvarh 3.69.2
ABSQ2 T2 C3-ACT
kvarh 3.69.3
ABSQ2 T3 C3-ACT
kvarh 3.69.4
ABSQ2 T4 C3-ACT
kvarh 3.69.5
ABSQ2 T5 C3-ACT
kvarh 3.69.6
ABSQ2 T6 C3-ACT
Power Excesses
3.69.0
ABSQ2 TOTAL C3-ACT
Consumption per Q2 Reactive Energy
tariff periods from the last billing
period (if active), included in the total
3.69.x.01 where x = tariff (period)
Excesses from last billing period (if
active)
3.22.x.01 where x = tariff (period)
Power Excesses 3.22.1
EXCES T1 C1- C01
Power Excesses 3.22.2
EXCES T2 C1- C01
Power Excesses 3.22.3
EXCES T3 C1- C01
Power Excesses 3.22.4
EXCES T4 C1- C01
Power Excesses 3.22.5
EXCES T5 C1- C01
Maximums 3.22.6
EXCES T6 C1- C01
Excesos del último período de
facturación (si están activos)
3.22.x donde x = tarifa (período)
Maximums from the last billing period
(if active ) included in the total
3.26.x.01 where x = tariff (period)
Maximums 3.26.1
MAXDEM T1 C3-ACT
Maximums 3.26.2
MAXDEM T2 C3-ACT
Maximums 3.26.3
MAXDEM T3 C3-ACT
Maximums 3.26.4
MAXDEM T4 C3-ACT
Maximums 3.26.5
MAXDEM T5 C3-ACT
Maximums 3.26.6
MAXDEM T6 C3-ACT
L31-
L37
Maximums 3.26.0
MAXDEM TOTAL C3-ACT
Máximas del último período de
facturación (si están activas), incluido
el total
3.26.x.01 donde x = tarifa
(período)
4.4.5.- Screen L4 (INFORMATION)
This screen accesses information not relevant to the contract billing values. This is a
MENU screen. It provides access to other dependant MENU screens as shown below:
Table 12 Screen L4. Information.
Screens Text Comments
L40
OPERATIONAL
INDICATORS
This is used to check the proper working of the
equipment in all its main areas during installation
or during later, on site checks.
L41
POWER
CONTRACTS
This is used to indicate the values of the
contracted powers. It is applied to calculate
power excesses.
L42
TRANSFORMATION
RATIOS
This shows information on transformation ratios.
