Page no. 18
4.4.6.3.- Screen L43 (INFORMATION: CURRENT VALUES)
This screen shows information on current power, maximum power, totals and power
from the last integration period (15 minutes as a default). As this data does not
correspond to any specific contract but is data general to all, field B will have the value
0. It is a DATA screen.
Table 16 Screen L43. Information: current values.
Code
Screen Text
OBIS No OBIS
Comments
0.18.0 IMP
TOTAL A+: This shows the current total for
Active Energy taken from the system
0.28.0 EXP
TOTAL A-: This shows the current total for
Active Energy exported to the system
0.58.0 Q1
TOTAL R1 This shows the current total for
Reactive Energy in Quadrant 1
0.68.0 Q2
TOTAL R2: This shows the current total for
Reactive Energy in Quadrant 2
0.78.0 Q3
TOTAL R3: This shows the current total for
Reactive Energy in Quadrant 3
0.88.0 Q3
TOTAL R4: This shows the current total for
Reactive Energy in Quadrant 4
0.14.0 PMD+
CURRENT INPUT POWER: This shows the
average input power that is being integrated
during the current integration period
0.24.0 PMD-
CURRENT OUTPUT POWER: This shows
the average output power that is being
integrated during the current integration
period
0.15.0 TPMD+
LAST PERIOD INPUT POWER: This shows
the average input power that is being
integrated during the last integration period
L43
CURRENT
0.25.0 TPMD-
LAST PERIOD OUTPUT POWER: This
shows the average output power that is
being integrated during the last integration
period
