RGU-10A , RGU-100A
Instruction Manual
8.3.2.- TRIPPING DUE TO TEST OR COMMUNICATIONS
Función 0x05 is used for these variables.
Table 24: Modbus Memory Map: tripping due to test or communications.
Tripping due to test or communications
Parameter Format Address Valid data range
Default
value
Tripping due to TEST bool 07D0
FF00: Activate TEST
0000: Finish TEST
0000
Tripping due to Communications bool 07F8
FF00: Tripping of channel
0000: Channel reset
0000
8.3.3.- DEVICE CONFIGURATION VARIABLES
The following functions are used for these variables:
Function 0x03: Reading of registers
Function 0x10:Writing multiple registers.
8.3.3.1.- Configuration of the trip
Table 25: Modbus Memory Map: Configuration of the trip.
Configuration of the trip
Configuration
parameter
Format Address Valid data range
Default
value
Delay or Relay curve Unit [16] 3778
1: Curve INS, 2: Curve SEL, 100 ms, 200 ms,
300 ms, 400 ms, 500 ms, 800 ms,
1000 ms, 2000 ms, 3000 ms, 5000 ms
1
Trip current Unit [16] 3779
30 mA, 100 mA, 200 mA, 300 mA, 500 mA,
750 mA, 1000 mA, 1500 mA, 2000 mA,
3000 mA, 5000 mA, 10000 mA, 30000 mA
30 mA
8.3.3.2.- Pre-alarm relay configuration
Table 26: Modbus Memory Map: Pre-alarm relay configuration.
Pre-alarm relay configuration
Configuration
parameter
Format Address Valid data range
Default
value
Pre-alarm current Unit [16] 377A 25 ... 100 % 50 %
Pre-alarm Operation Unit [16] 377B
0: Deactivated
1: Activated with deactivated latch
2: Activated with activated latch
1
Pre-alarm relay delay Unit [16] 377C 1000, 3000, 5000 ms 1000 ms
Pre-alarm polarity Unit [16] 380E
0: standard polarity
1: positive polarity
0
