RGU-10A , RGU-100A
Instruction Manual
9 TECHNICAL FEATURES
9.1 - RGU-10A / RGU-100A
AC Power supply
Rated voltage
RGU-10A RGU-100A
230 V ~ ± 15% 110 ... 230 V
Frequency 50... 60 Hz
Consumption 6.5 VA
Installation category CAT III 300V
Monitoring features
Protection Type Type A ultaimmunised
Sensitivity (In) 0.03 - 0.1 - 0.2. - 0.3 - 0.5 - 0.75 - 1 - 1.5 - 2 - 3 - 5 - 10 - 30 A
Adjustable trigger delay INS - [S] - 0.1 - 0.2 - 0.3 - 0.4 - 0.5 - 0.8 - 1 - 3 - 5 s
Rated frequency of the monitored circuit 50 / 60 Hz
Rated residual non-operating current 0.8 IΔn
Rated short-time withstand current (Icw)
32 kA / 1s
Conditional short-circuit differential current (Ic)
1500 A
Uimp of the voltage source
4 kV (CAT III)
Relay outputs
Quantity 2
Maximum voltage open contacts 230 V ~ ± 15%
Maximum current
6 A
Maximum switching power
1500 VA
Electrical life (250V ~ / 5A)
60x10
3
Cycles
Mechanical life
10x10
6
Cycles
TRIP / RESET input
Type
Voltage 110 ... 230 V~
Insulation
3 kV
Input impedance
94 KΩ
RS-485 communications
Communication protocol Modbus RTU
Baud rate 4800 - 9600 - 19200 - 38400 - 57600 - 115200 bps
Data bits
8
Stop bits
1 - 2
Parity
without, even, odd
User interface
Display LCD custom (negative)
Keyboard 3 keys
LED 2 LED
Environmental features
Operating temperature -10 ºC ... +60 ºC
Storage temperature -20 ºC ... +70 ºC
Relative humidity (without condensation) 5 ... 95%
Maximum altitude 2000 m
IP protection rating IP30, Front: IP40
