General Information 24
5. Lift the assembly straight up to remove it.
Adding a Scanner
1. Align each tab on a Scanner Module with
the corresponding slots in the previous
module.
2. Press the two assemblies together until
the retaining catches lock.
3. Place the TERMINATOR into the last
scanner in the stack.
Tab
Slot
Terminator
