Cirris CH2 - Cirris CH2 Category Instruction Descriptions

Custom Instructions 42
The “Cirris CH2” Category
The instructions for this category are Compliance Limited 2W Resistance, Compliance
Limited 4W Resistance, Verification, Zero Ohm, EBox Zero Ohm, EBox overload test,
Measure Diode Voltage, Measure Probe Resistance, Measure 4-wire Probe Resistance,
Disable Shorts Test, Two Point LV Isolation Test, Two Point HV Isolation Test, Bulk LV
Isolation Test, Bulk LV Isolation Test with Search, and Bulk HV Isolation Test.
 Compliance Limited 2W Resistance
This instruction allows you to control the voltage and current used in a test.
EXAMPLE: In the “Current Voltage
Editor,” you will be able to enter a
specific number for the amount of
the Source Voltage and Source
Current used in the test.
 Verification and Zero Ohm
These instructions are found in the CH2 Performance Verification Manual; refer to
that manual for more information.
